record K 32 3-wing revolving door – The record K32 3-wing automatic or manual revolving door is available in various design options.

record K 32 3-wing revolving door Technical data Drawings BIM Documents

Three-wing revolving door in manual or automatic execution which is available in different design variants.

record K 32 3-wing revolving door – The record K32 3-wing automatic or manual revolving door is available in various design options.
record K 32 3-wing revolving door – The record K32 3-wing automatic or manual revolving door is available in various design options.  record K 32 3-wing revolving door – The record K32 3-wing automatic or manual revolving door is available in various design options.
The three-wing revolving door record K 32 is optionally available with a showcase, night lock or escape function. You can choose between the proven ceiling drive and the invisible underfloor drive, the colour design in any RAL or anodised colour or the all-glass version for a particularly transparent appearance. The record K 32 can be equipped with a switchable controller for reduced speed to make access easier for wheelchair users or people with reduced mobility.
Due to the 120° division of the turnstile, each 3-leaf revolving door offers comfortable use for all users and persons.

The hood construction consists of a stable steel construction including thermal insulation, while the hood, the flush ceiling and the dust roof are made of aluminium.

Drive variants using the latest technology in conjunction with the highest level of safety equipment are an indispensable standard for record.

Optional burglar resistance class RC 2 or RC 3 according to EN 1627 for increased security requirements.

Certificates: TÜV type approval (EN 16005), burglar resistance class RC 2 & RC 3 (DIN EN 1627


Features

  • provides a very comfortable 120° wide compartment
  • available in any colour
  • highly engineered and reliable drive components
  • controllable speed to meet customer needs
  • suitable for disabled use
  • ceiling fitted drive or underfloor drive available

Benefits

  • smoothness of operation
  • tried and tested
  • accommodates the passage of large and bulky items
  • speed can be controlled for less able customers



Options

  • ceiling fitted drive
  • optional central showcase
  • night shutters
  • emergency escape function
  • invisible underfloor fitted drive
  • switchable control to reduce operation speed
